GWN7670 Wi-Fi 7 Indoor Dual-Band Access Point

GWN7670 Wi-Fi 7 Indoor Dual-Band Access Point

£101.38 GBP
Sale price: £101.38 GBP Regular price: £0.00 GBP
(VAT Incl.)
Shipping calculated at checkout.
  • Energy Efficiency: Low Energy support
  • Technology: Next-gen standard for improved performance and reliability
In stock, 50 units
EAN: 6947273705536.00
SKU: GWN7670
Vendor: Grandstream
Order within xx hours for delivery on
Quantity
  • Antenna gain 5 single frequency antennas 2.4GHz x 2, gain 3.5dBi 5GHz x 2, gain 5.5dBi BT gain 3.5dBi
  • Bluetooth BLE 5.3
  • Concurrent Clients 256
  • Coverage Range Up to 175 meters *coverage range can vary based on environment
  • Dimensions 185mm x 185mm x 44.5mm
  • Interface 2x 2.5G Ethernet WAN/LAN
  • Mounting Indoor wall mount or ceiling mount, kits included
  • Operating humidity 10% to 90% Non-condensing
  • Operating temperature 0°C to 45°C
  • QoS 802.11e/WMM, VLAN, TOS
  • Wi-Fi and System Security WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
  • Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax/be
  • Frequency 2.4GHz Radio: 2400 - 2483.5 MHz 5GHz Radio: 5150 - 5895 MHz *Not all frequency bands can be used in all regions
  • Weight 527g
  • Maximum Transmit Power 5G: 26dBm 2.4G: 26dBm *Maximum power varies by country, frequency band and MCS rate
  • Storage Temperature -30°C to 60°C
  • GWN7670 Access Point
  • Mounting Kits
  • Quick Installation Guide
  • Ethernet Cable

Datasheet



Overview

The GWN7670 is a new generation enterprise-grade Wi-Fi 7 access point, ideal for small-to-medium-sized businesses to build next-generation Wi-Fi networks. It offers dual-band 2x2:2 MIMO with DL/UL OFDMA technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. The GWN7670 improves bandwidth utilization and anti-interference ability with multi-RU and Preamble Puncturing technology. With 4096 QAM modulation, Wi-Fi 7 achieves a significant increase in data transfer rates.


Technical Features
  • Next-gen standard for ultra-high throughput and low latency
  • Both 2.4 GHz and 5 GHz for reliable dual-band coverage
  • Efficient spectrum use, enhanced in congested environments
  • Higher modulation density for superior throughput
  • 688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz) = ~3.6 Gbps total
  • Supports one WAN and one LAN with PoE+ (802.3at)
  • Automatically adjusts power based on the switch/power source
  • Ideal for open office layouts and medium-range coverage
  • Great for dense usage environments
  • Bluetooth Low Energy support for location services and IoT endpoints
  • Ensures low-latency experience for VoWiFi, video, and gaming
  • Secure firmware, with unique certs and passwords per device
