Grandstream HT813 Analogue Telephone Adaptor

Grandstream HT813 Analogue Telephone Adaptor

£72.24 GBP
Sale price: £72.24 GBP Regular price: £0.00 GBP
(VAT Incl.)
Shipping calculated at checkout.
  • SIP Accounts: 2 SIP profiles
  • Network Interfaces: Dual LAN and WAN ports
  • Conferencing: Supports 3-way voice conferencing
Out of stock
EAN: 6947273702634
SKU: HT-813
Vendor: Grandstream
Order within xx hours for delivery on
Quantity
  • Telephone Interfaces: 1x RJ11 FXS port, 1x RJ11 FXO PSTN line port with lifeline support
  • Network Interface: Dual 10/100Mbps (RJ45) ports with integrated NAT router
  • LED Indicators: POWER, LAN, WAN, FXS, FXO
  • Voice & Fax: Supports T.38 Fax-over-IP, advanced line echo cancellation, dynamic jitter buffer
  • Voice Codecs: G.711, G.723.1, G.729A/B, G.726, iLBC, OPUS
  • Telephony Features: Caller ID, call waiting, call transfer, call forwarding, hold, DND, 3-way conferencing
  • Security: SRTP for media encryption, TLS/SIPS/HTTPS for signaling
  • Provisioning: HTTP/HTTPS, TFTP, SSH, TR-069, secure AES-encrypted automated provisioning
  • QoS: 802.1Q VLAN tagging, ToS, DiffServ, MPLS
  • Power Supply: 12V DC, 0.5A (100–240V AC input)
  • Environmental: Operating 0°C–40°C, Storage -10°C–60°C, Humidity 10–90% non-condensing
  • Dimensions: 130.5 x 90.5 x 29 mm
  • Weight: 0.142 kg
  • 1xHT813
  • 1X12V Power Adapter
  • 1xEthemet cable
  • 1x Quick installation guide
  • 1x GPL Statment

Datasheet

Overview

The HT813 is a powerful analog telephone adapter designed for users looking to connect their analog devices to a VoIP network in either a home or office. It features 1 analog telephone FXS port and 1 PSTN line FXO port in order to offer backup lifeline support using a PSTN line. The FXS port extends VoIP service to one analog device thanks to the HT813’s compact size, HD voice quality and multi auto provisioning options.

Technical Features
  • SIP Accounts: Supports 2 SIP profiles through 1 FXS port and 1 FXO port
  • Network Interfaces: Dual 10/100 Mbps LAN and WAN ports
  • Lifeline Support: FXS port is hard-relayed to FXO port during power outage
  • Conferencing: Supports 3-way voice conferencing
  • Provisioning: Automated and secure provisioning options
  • Fax Support: T.38 Fax for Fax-over-IP
  • Failover Protection: Automatically switches to secondary SIP server if the main server loses connection
  • Integration: Compatible with Grandstream UCM series IP PBXs for Zero Configuration provisioning
  • Security: Strong AES encryption with unique security certificate per unit
