GRP2601

GRP2601

£37.26 GBP
Sale price: £37.26 GBP Regular price: £0.00 GBP
(VAT Incl.)
  • 2 SIP account, 2 lines
  • 5-way audio conferencing
In stock, 477 units
EAN: 6947273703105
SKU: GRP2601
Vendor: Grandstream
Order within xx hours for delivery on
Quantity
  • Corded or cordless: Corded
  • Technology: VoIP
  • Function keys: With call key, With hands free kit, With mute key, With navigation key, With redial key
  • Headset port: With headset port
  • Power source: Mains powered
  • Type of display: Colour display
  • Connectivity: RJ45 connection
  • Wall mounting: With optional wall mounting
  • ATEX certified: Without ATEX certification
  • Grandstream GRP2601
  • Handset with cord
  • Base stand
  • Universal Power Supply Unit (GRP2601 Only)
  • network cable
  • Quick Installation Guide

Datasheet

Overview

As a part of the GRP series of Carrier-Grade IP Phones, the GRP2600 series of Essential IP phones are equipped for zerotouch provisioning for mass deployment and easy management. The line features a sleek design and a suite of next-generation features including 5-way voice conferencing, integrated PoE models, EHS support, and multi-language support. The GRP series includes carrier-grade security features to provide enterpriselevel security, including secure-boot, dual-firmware images, and encrypted data storage

Technical Features
  • Protocols/Standards SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR069, SNMP, 802.1x, TLS, SRTP, IPv6
  • Network Interfaces Dual switched auto-negotiation 10/100 Mbps Ethernet ports
    Graphic Display: 132 x 48 (2.41’’) LCD display
  • Feature Keys 4 XML programmable context sensitive soft keys, 5 (navigation, menu) keys.
    8 dedicated function keys for: MESSAGE (with LED indicator), TRANSFER, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOL
  • Voice Codecs and Capabilities Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), G.723, iLBC, OPUS.
    In-band and out-of-band DTMF (in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC, AJB
  • Telephony Features Hold, transfer, forward, 5-way conference, call park, call pickup, downloadable phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 800 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalized music ringtones and music on hold, server redundancy and fail-over
  • Auxiliary Ports RJ9 headset jack (allowing EHS with Plantronics & Jabra & Sennheiser headsets)
    Base Stand: Yes, 1 angle position available (45°), Wall Mountable (*wall mount sold separately)
  • QoS Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
  • Security User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control, secure boot
  • Multi-language English, Chinese, Korean, Japanese, German, Italian, French, Spanish, Portuguese, Russian, Croatian and more
  • Upgrade/Provisioning Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file
  • Power & Green Energy Efficiency Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA
    PoE: IEEE802.3af Class 1, 3.84W; IEEE802.3az (EEE) (GRP2601P Only)
  • Temperature and Humidity Operation: 0°C to 40°C
    Storage: -10°C to 60°C
    Humidity: 10% to 90% Non-condensing
