Best Seller
Grandstream GRP2603

Grandstream GRP2603

£55.08 GBP
Sale price: £55.08 GBP Regular price: £0.00 GBP
(VAT Incl.)
  • 3 lines
  • 6 SIP accounts
  • up to 3 call appearances
In stock, 242 units
EAN: 6947273703181
SKU: GRP2603
Vendor: Grandstream
Order within xx hours for delivery on
Quantity
  • Display: 2.7 inch (132x64) backlit graphical LCD Display
  • Lines: 3 Lines
  • SIP Accounts: 6 SIP Accounts
  • Audio Conferencing: 5-way audio conference
  • Network Interfaces: Dual switched autosensing 10/100/1000 Mbps Gigabit Ethernet ports with integrated PoE (GRP2603P only)
  • Wi Fi: No
  • Device Management: Yes, GDMS
  • Custom Faceplates: Yes

Grandstream GRP2603

Datasheet

Overview

The Grandstream GRP2603 is a professional-grade IP phone designed for efficient communication in business environments. It features a user-friendly interface with a high-resolution color display, supporting multiple SIP accounts for versatile connectivity. This model offers HD audio quality, ensuring clear voice calls, and includes essential telephony functions such as call hold, transfer, and conferencing. Its robust build and advanced security protocols make it a reliable choice for enterprises seeking a secure and scalable VoIP solution.

Technical Features
Protocols/Standards
  • SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR069, SNMP, 802.1x, TLS, SRTP, IPv6
Network Interfaces
  • Dual switched auto-negotiation 10/100/1000 Mbps Ethernet ports, integrated PoE (GRP2603P only)
Graphic Display
  • 132 x 64 (2.7’’) backlit graphical LCD display
Feature Keys
  • 3 line keys with dual-color LED and support for 6 SIP accounts, 4 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 9 dedicated function keys for: MESSAGE(with LED indicator), TRANSFER, HOLD, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOLAuxiliary Port RJ9 headset jack (allowing EHS with Plantronics & Jabra &Sennheiser headsets)
Voice Codecs and Capabilities
  • Support for G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G.723,iLBC, OPUS, in- band and out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC, AJB
Telephony Features
  • Hold, transfer, forward, 5-way conference, call park, call pickup, shared-call appearance(SCA)/bridged-line-appearance(BLA), downloadable phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 800 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalized music ringtones and music on hold, server redundancy and fail-over
HD Audio
  • Yes, HD handset and speakerphone with support for wideband audio
Base Stand
  • Yes, 2 angle positions available (39° & 45°), Wall Mountable (*wall mount sold separately)
QoS
  • Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
  • User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control, secure boot
Multi-language
  • English, Chinese, Korean, Japanese, German, Italian, French, Spanish, Portuguese, Russian, Croatian, and more
Upgrade/Provisioning
  • Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file
Physical
  • Dimension: 214mm (L) x 206mm (W) x 68mm (H) (with handset)
  • Unit weight: 780g
