StarTech CAT6a Ethernet Cable

StarTech CAT6a Ethernet Cable

£23.50 GBP
Sale price: £23.50 GBP Regular price: £0.00 GBP
(VAT Incl.)
Shipping calculated at checkout.
  • 100W Power over Ethernet
  • RJ45 Connectors
Out of stock
EAN: 65030896849
SKU: V295692
Vendor: StarTech
Order within xx hours for delivery on
Quantity
  • Category: Cat6A Network Patch Cord
  • Length: 7.5m
  • Color: White
  • Data Rate: 10Gbps
  • Bandwidth: 500 MHz
  • Structure: 4 Pair S/FTP
  • Connector: Snagless RJ45 with strain reliefs
  • Jacket & Insulation: EVA, Al(OH)3; LSZH
  • Wire Gauge: 27 AWG
  • Conductor Material: 100% Copper
  • Verification: ETL Verified; ANSI/TIA-568.2-D
  • Compatibility: Supports Cat6 and earlier standards
  • 1 - CAT6A LSZH Ethernet Cable

Datasheet

Overview

Cat6a Ethernet Low-Smoke Zero-Halogen (LSZH) Shielded cables support Multi-Gigabit/Multi-speed 1/2.5/5Gbps/10Gbp connections. It offers robust protection against electromagnetic interference (EMI/RFI) and noise, ensuring a fast, safe, and reliable network. LSZH Cat6a Network Cables are more eco-friendly than PVC cables. In the event of a fire, LSZH cables produce low levels of corrosive fumes and smoke. Low levels of acrid combustion pollutants promote increased visibility, resulting in safe and quick building evacuations by staff and first responders.

Technical Features
  • Cat6A Ethernet Cable: High-performance cable for error-free 1/2.5/5/10Gbps multi-gigabit connections; low Near-End Crosstalk (NEXT) and Return Loss (RL); individually tested; ETL verified to ANSI/TIA-568.2-D standards.
  • Shielded Cat6A Cable: Individual twisted pairs wrapped in foil; outer braided shield; shielded RJ45 connectors with gold-plated pins; protects against EMI/RFI interference.
  • 100W Power over Ethernet: 100% stranded copper wire supports stable PoE power up to 100W; compliant with IEEE 802.3bt (Type 4 and lower).
  • Durable LSZH Jacket: Low Smoke Zero Halogen (LSZH) jacket resists bending and produces less dense, corrosive smoke than PVC; braided construction enhances durability.
