StarTech.com 20" Locking USB C

Name: StarTech.com 20" Locking USB C
Brand: StarTech
SKU: V276818
Price: 14.21 GBP
Availability: OutOfStock

£14.21 GBP

£14.21 GBP ~~Regular price:~~

(VAT Excl.)

Shipping calculated at checkout.

Deliver 8K Video
Charge Your Mobile Devices

Out of stock

EAN: 65030892957

SKU: V276818

Vendor: StarTech

Order within xx hours for delivery on

Product Specification

Length: 20 inch (50 centimeter)
Data Transfer: USB 3.2 Gen 2 (10Gbps)
Video Support: Up to 8K @ 60Hz, 4K @ 144Hz
Power Delivery: PD 3.0, up to 20V and 5A
Connector Type: USB-C screw locking male to USB-C male
Outer Diameter: 0.19" (4.8 mm)
Wire Gauge: 32 AWG
Jacket: TPE
EMI Shield: Al-Mylar foil with braid

Box Content

1 - 50 cm Side Screw Locking USB-C Gen 2 10Gbps Cable

Documents

Datasheet

Technical Features

Performance: 20" (50cm) side screw locking USB-C to USB-C cable compliant with SuperSpeed USB 3.2 Gen 2 (10Gbps); supports DisplayPort 1.4 Alt Mode up to 8K @ 60Hz and up to 100W (5A) Power Delivery 3.0; Thunderbolt 3 compatible
Durability: Tested for 10,000+ insertions and 4,000+ bend cycles at +/-60°; flexible TPE jacket with strain relief; non-toxic, halogen-free, RoHS-certified material
Construction: 32 AWG conductors; Al-Mylar foil with 85% braid coverage EMI shielding for signal integrity; M2 screw (1.2"/30.5mm) with knurled grip for easy installation and removal; compatible with USB 3.2 and earlier versions
Applications: Designed for docking stations with dual side-locking USB-C ports (e.g., DK31C3HDPD); removable screw for hard drive enclosures and external storage; suitable for charging and connecting USB-C/Thunderbolt 3 laptops such as MacBook, Surface Book, and ThinkPad

StarTech.com 20" Locking USB C

£14.21 GBP

£14.21 GBP ~~Regular price:~~

(VAT Excl.)

Overview

This side screw locking USB-C 3.2 Gen 2 10Gbps cable lets you connect your USB Type-C devices for syncing, charging, and powering your devices. The USB-C cable is also compatible with Thunderbolt 3 ports, allowing you to connect and charge your USB-C devices using your Thunderbolt 3 laptop. This cable features dual locking screws that can securely connect to your USB-C peripherals and can prevent accidental disconnection from your devices such as external hard drives or docking stations. The screws are designed to fit all devices that use a standard side screw locking input, such as StarTech.com's DK31C3HDPD.
