Overview
Designed with a durable aluminum alloy frame and toughened glass front panel, the device carries IP65 weatherproof and IK09 impact-resistant ratings, making it suitable for both indoor and outdoor deployment. The surface-mount version is ideal for installations where flush mounting is not practical, especially on door frames or narrow spaces Designed with a durable aluminum alloy frame and toughened glass front panel, the device carries IP65 weatherproof and IK09 impact-resistant ratings, making it suitable for both indoor and outdoor deployment. The surface-mount version is ideal for installations where flush mounting is not practical, especially on door frames or narrow spaces.
Technical Features
- Image Sensor: 1/1.8" Progressive Scan CMOS
- Maximum Resolution: 3840 × 2160 (8MP / 4K)
- Lens: Fixed 4mm Lens
- Field of View: 90° Horizontal
- Minimum Illumination: 0.0005 Lux (Color)
- Wide Dynamic Range: 130 dB WDR
- Supplement Light Type: IR & White Light (Smart Hybrid Light)
- Light Range: Up to 60m
- Video Compression: H.265+ / H.265 / H.264+
- Frame Rate: Up to 25/30 fps
- Deep Learning Analytics: Human & Vehicle Classification
- Network Interface: 1 × RJ45 10/100 Mbps Ethernet
- Storage Support: MicroSD Card up to 512GB
- Power Supply: 12V DC or PoE (IEEE 802.3af)
- Power Consumption: Max. 9.5W
- Weather Protection: IP67 Rated
- Operating Temperature: -30°C to 60°C
