ATEN UC232A1

Name: ATEN UC232A1
Brand: ATEN
SKU: UC232A1
Price: 14.75 GBP
Availability: InStock

£14.75 GBP

£14.75 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

USB To Serial Connectivity Made Easy

In stock, 30 units

EAN: 4719264643897

SKU: UC232A1

Vendor: ATEN

Order within xx hours for delivery on

Product Specification

Converts USB interface to RS-232 serial connection
Ideal for connecting legacy serial devices to modern computers
Supports RS-232 serial communication standards
High-speed data transfer up to 921.6 Kbps
USB bus-powered operation with no external power adapter
Supports Windows, macOS, and Linux operating systems
Compatible with modems, POS systems, industrial equipment, and network devices
Plug-and-play installation with driver support
Compact and lightweight design for portable use
LED indicator for power and activity status

Box Content

1 × ATEN UC232A1 USB-to-RS-232 Adapter
1 × Driver CD / Software
1 × User Manual / Quick Installation Guide

Documents

Datasheet

Technical Features

Model: UC232A1
Device Type: USB to RS-232 Serial Converter
USB Interface: 1 × USB Type-A Male
Serial Interface: 1 × DB-9 Male
USB Standard: USB 2.0 compliant
Data Transfer Rate: Up to 921.6 Kbps
Cable Length: 1 meter
LED Indicator: Power / Data Activity (Orange)
Power Source: USB Bus Powered
Operating Temperature: 0°C – 40°C
Storage Temperature: −20°C – 60°C
Humidity: 0 – 80% RH (Non-condensing)
Housing Material: Plastic
Dimensions: 6.59 × 3.40 × 1.60 cm
Weight: Approx. 0.06 kg

ATEN UC232A1

£14.75 GBP

£14.75 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Overview

The ATEN UC232A1 USB-to-RS-232 Adapter provides a simple and reliable way to connect legacy serial devices to modern computers that only have USB ports. Designed with a DB-9 serial connector and USB Type-A interface, it allows communication with equipment such as modems, industrial automation systems, POS devices, scanners, and networking hardware. The adapter supports high data transfer speeds up to 921.6 Kbps and complies with USB specifications for stable performance. It is bus-powered, meaning it draws power directly from the USB port without requiring an external adapter. With support for Windows, macOS, and Linux operating systems, the UC232A1 is widely used in IT maintenance, industrial control environments, and laboratory equipment connectivity. Its compact design and 1-meter cable provide flexible installation in desktop or field environments.
