ATEN 4 Port HDMI Splitter Audio 4K60

Name: ATEN 4 Port HDMI Splitter Audio 4K60
Brand: ATEN
SKU: VS182B
Price: 85.7 GBP
Availability: InStock

£85.70 GBP

£85.70 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

Plug-and-play
LED indication

In stock, 19 units

EAN: 4719264645402

SKU: VS182B

Vendor: ATEN

Order within xx hours for delivery on

Product Specification

Input Interface: 1 x HDMI Type A Female (Black)
Input Impedance: 100 Ω
Max Distance: 5 m at 4K@60Hz (4:4:4)
Video Output Interfaces: 2 x HDMI Type A Female (Black)
Output Impedance: 100 Ω
Output Distance: 5 m at 4K@60Hz (4:4:4)
Max Data Rate: 18 Gbps (6 Gbps per lane)
Max Pixel Clock: 600 MHz
Compliance: HDMI (3D, Deep Color)

Box Content

1 x VS182B 2-Port True 4K HDMI Splitter
1 x 0AD6-1005-26EG Power adapter
1 x LIN5-19V2-V21G HDMI cable
1 x User Instructions

Documents

Datasheet

Technical Features

Video Distribution: Connects one HDMI source to two HDMI displays at the same time
HDMI Support: HDMI (3D, Deep Color, 4K); HDCP 2.2 compatible
HDR Support: Supports HDR10+
Max Resolution: Up to 4096 x 2160 / 3840 x 2160 @ 60 Hz (4:4:4)
Transmission Distance: Up to 15 m (1920 x 1200) / 5 m (True 4K)
Pixel Clock: Up to 600 MHz
Data Rate: Up to 18 Gbps (6 Gbps per lane)
LED Indicators: Power status and source device indication
EDID Control: EDID Expert™ with DIP switch (Port 1, Default, Auto selection)
Setup: Plug-and-play, no software installation required

ATEN 4 Port HDMI Splitter Audio 4K60

£85.70 GBP

£85.70 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Overview

The VS182B True 4K HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to two displays at the same time. It supports all HDMIenabled equipment, such as DVD players, satellite set- top boxes and all HDMI monitors, displays, projectors, or TVs.
