ASUS AM5 PRIME B840M-K M-ATX

Name: ASUS AM5 PRIME B840M-K M-ATX
Brand: ASUS
SKU: 90MB1PK0-M0EAY0
Price: 106.18 GBP
Availability: InStock

£106.18 GBP

£106.18 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

AMD Ryzen 9000 Series Ready
Stable WiFi 6E Connection

In stock, 39 units

EAN: 4711636435048

SKU: 90MB1PK0-M0EAY0

Vendor: ASUS

Order within xx hours for delivery on

Product Specification

Socket & Chipset AMD Socket AM5 for Ryzen™ 9000/8000/7000 Series, powered by the B840 chipset
Memory 2 x DIMM slots, max. 128GB DDR5 (supports over 8000+ MT/s via OC)
Storage & Expansion 2 x PCIe 4.0 M.2 slots (Type 2280), 4 x SATA 6Gb/s ports, 1 x PCIe 4.0 x16 slot, and 1 x PCIe 3.0 x16 (x4 mode) slot
Networking & Audio Realtek 2.5Gb Ethernet with LANGuard and 7.1 Surround Sound
I/O & Headers USB 5Gbps Type-C header, USB 5Gbps Type-A, USB 2.0 ports, HDMI 2.1, and Addressable Gen 2 RGB headers
Power & Cooling 8+2+1 phase power design with DIGI+ VRM, comprehensive heatsinks, and Fan Xpert 2+

Box Content

Motherboard
Cables2 x SATA 6Gb/s cables
Miscellaneous1 x ASUS WiFi Q-Antenna
1 x M.2 rubber package
2 x Screw packages for M.2 SSD
Documentation1 x Quick start guide

Documents

Datasheet

Technical Features

CPU Support Socket AM5 native compatibility with AMD Ryzen 9000, 8000, and 7000 Series desktop processors
Power Design 8+2+1 Phase Power Design with discrete MOSFETs and DIGI+ VRM for stable voltage control
Memory Support DDR5 support up to 128GB across 2 slots, up to 8000+ MT/s (OC) with AEMP optimization
Storage Dual PCIe 4.0 M.2 slots with up to 64 Gbps transfer speeds
Networking 2.5Gb Ethernet with ASUS LANGuard protection
USB Connectivity Front-panel USB 5Gbps Type-C header support
Display Output HDMI 2.1 supporting 4K @ 60Hz (with supported CPUs)
Cooling VRM heatsink, PCH heatsink, and hybrid fan headers managed by Fan Xpert 2+
Diagnostics Q-LED Core onboard troubleshooting indicators for CPU, DRAM, VGA, and Boot status
Durability SafeSlot Core+ reinforced PCIe slot with stainless-steel brace for GPU protection
AI Features AI Cache Boost and ASUS AI Advisor for performance optimization and system guidance

ASUS AM5 PRIME B840M-K M-ATX

£106.18 GBP

£106.18 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Overview

The ASUS Prime B840M-K is a budget-friendly Micro-ATX motherboard designed for the AMD AM5 platform, supporting Ryzen 9000, 8000, and 7000 series processors. It features a reliable 8+2+1 power stage design and comprehensive cooling to handle everyday productivity and entry-level gaming. Connectivity is centered on modern essentials, including DDR5 memory support up to 8000+ MT/s, dual PCIe 4.0 M.2 slots, and 2.5Gb Ethernet. This board is an ideal choice for builders seeking a cost-effective, "AI PC" ready foundation without the premium price of high-end chipsets.
