Algo 8180 SIP Alerter

Algo 8180 SIP Alerter

£342.17 GBP
Sale price: £342.17 GBP Regular price: £0.00 GBP
(VAT Incl.)
Shipping calculated at checkout.
  • Gen 2 Public address (PA) IP speaker.
In stock, 159 units
EAN: 8180G2
SKU: Algo8180
Vendor: Algo
Order within xx hours for delivery on
Quantity
  • Gen 2 Public address (PA) IP speaker.
  • Secure SIP using TLS and SRTP.
  • Multicast scalable. Wideband HD voice for high intelligibility speech.
  • Dynamic volume control responsive to ambient noise levels.
  • Talkback capable speaker.
  • Customize WAV files for emergency notification / alerting and telephone loud ringing.
  • Configuration via user friendly web interface or auto-provisioning.
  • PoE (IEEE 802.3af).
  • Ideal for a school or college classroom, office, lunch room, kitchen, restaurant, etc.
  • Algo 8180 SIP Audio Alerter unit
  • Wall mounting bracket
  • User documentation or quick-start guide

datasheet

Overview

The Algo 8180 SIP Audio Alerter is a SIP compliant PoE network audio device for loud ring and voice paging applications using dual endpoints. When registered with a SIP server, one endpoint will play an audio file from internal memory upon ring detection. The second endpoint will auto-answer for voice paging. Equipped with a high efficiency integrated amplifier and tuned high quality loud speaker, the 8180 is significantly louder than a typical telephone. Outputs for external speaker, slave amplifier, or visual alerter plus multicasting capability enable many more options to enhance notification and alert capabilities. Configuration is possible using the feature buttons or web interface.

Technical Features
  • Power Input
    • POWER INPUT: PoE (IEEE 802.3af Class 0) 48V, 12.95W
    • MAX POWER: 12.95W
    • IDLE POWER: Nominal 2.5W
  • SIP
    • SIP EXTENSIONS: 50 Page (Capable of hands-free talkback), 10 Emergency Alert, 10 Ring
    • SIP SIGNALLING/TRANSPORT PROTOCOLS: UDP, TCP, TLS, RTP, SRTP
    • Multicast + Third-Party Compatibility:
      • RTP Multicast (Send and Receive 50 Zones)
      • Polycom Group Page
      • Singlewire InformaCast (additional license required)
      • Syn-Apps Revolution
  • Configuration & Provisioning
    • CONFIGURATION: Web interface or provisioning server
    • WEB INTERFACE: HTTP, HTTPS
    • PROVISIONING: TFTP, FTP, HTTP, HTTPS; DHCP Options 66, 150, 160; Reboot via SIP ‘check-sync’
    • SUPERVISION: Compatible with any third party SNMP monitoring software or the Algo 8300 Controller
  • Networking
    • NETWORKING: IPv4, DHCP, VLAN
    • LINK LAYER: LLDP, CDP
    • QOS: DSCP
    • NAT: STUN, TURN, CRLF Keep Alive, SIP Outbound
    • ADDRESS RESOLUTION: DNS, SRV Record
    • REDUNDANCY: Secondary and tertiary SIP server
    • TIME: NTP Server (up to four)
  • Audio
    • SPL: 106 dBA at 1m (120 dBA with 1186 horn)
    • MICROPHONE: Omnidirectional – talkback and ambient noise monitoring
    • AUDIO CODECS: G.711 u-law, G.711 A-law, G.722 Wideband
    • AUDIO MEMORY: 1 GByte audio storage
  • Input/Output
    • RELAY INPUT: Normally open or normally closed dry contact supervision using Algo 1202 Call Button, 1203 Call Switch, 1204 Volume Control or EOL resistor termination
    • RELAY OUTPUT: Max 30 V 50 mA (normally open)
  • Environmental & Mechanical
    • ENVIRONMENTAL: 0 to +40 °C (32 to 104 °F); 10-95% RH non-condensing. Dry indoor locations only.
    • DIMENSIONS (PRODUCT): 7″ x 4″ x 2.6″ (17.8cm x 10.2cm x 6.5cm)
    • WEIGHT (PRODUCT): 1.0 lbs (0.5 kg)
    • WEIGHT (SHIPPING): 1.6 lbs (0.7 kg)
