ATEN 4 PORT HDMI KVMP

Name: ATEN 4 PORT HDMI KVMP
Brand: ATEN
SKU: CS1794
Price: 322.2 GBP
Availability: InStock

£322.20 GBP

£322.20 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

Switch Four PCs Easily

In stock, 2 units

EAN: 4710423775718

SKU: CS1794

Vendor: ATEN

Order within xx hours for delivery on

Product Specification

Control four computers with one console
Supports HDMI video up to 4K UHD @ 30Hz
Integrated USB hub for peripheral sharing
Independent audio switching (speaker & mic)
Push button and hotkey switching
Mouse wheel switching for convenience
Hot‑plug and plug‑and‑play ease
EDID support for stable display compatibility
Compatible with Windows, Mac, Linux

Box Content

1 × ATEN CS1794 4‑Port USB HDMI/Audio KVMP™ Switch
4 × USB Type‑B to USB Type‑A Cables
4 × HDMI Cables
4 × 3.5mm Audio Cables
1 × Power Adapter
1 × Quick Start Guide

Documents

Datasheet

Technical Features

Brand: ATEN
Model: CS1794
Product Type: 4‑Port USB HDMI/Audio KVMP™ Switch
Computer Connections: 4
Console Ports: 1 × HDMI, 2 × USB Type‑A, 2 × 3.5mm Audio (Speaker/Mic)
KVM Ports: 4 × HDMI, 4 × USB Type‑B, 4 × 3.5mm Audio
USB Hub: 2 × USB 2.0 Type‑A (for peripheral sharing)
Maximum Video Resolution: 3840 × 2160 @ 30Hz
HDMI Compliance: HDMI 1.4
Switching Methods: Push Buttons, Hotkeys, Mouse Wheel
EDID Support: Yes
Hot‑Plug Support: Yes
Power Supply: External DC Adapter
Operating Temperature: 0°C – 50°C
Storage Temperature: −20°C – 60°C
Humidity: 0–80% RH (Non‑condensing)
Dimensions: Approx. 21.0 × 9.0 × 3.0 cm
Weight: Approx. 1.3 kg

ATEN 4 PORT HDMI KVMP

£322.20 GBP

£322.20 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Overview

The ATEN CS1794 4‑Port USB HDMI/Audio KVMP™ Switch enables seamless control of multiple computers from a single console while sharing USB peripherals and audio devices. Supporting HDMI video up to 4K UHD (3840 × 2160 @ 30Hz), it delivers crisp and clear visuals for productivity and multimedia applications. The built‑in USB 2.0 hub allows sharing of USB devices such as flash drives, printers, and webcams across all connected systems. Audio is conveniently managed with independent switching between computers for both speaker and microphone. Users can switch between systems using push buttons, hotkeys, or mouse wheel switching, offering flexible operation. A compact and plug‑and‑play design eliminates software configuration, making it ideal for office workstations, home studios, and mixed‑OS environments.
