ATEN 4 PORT HDMI 4K60 KVMP

Name: ATEN 4 PORT HDMI 4K60 KVMP
Brand: ATEN
SKU: CS1824
Price: 357.89 GBP
Availability: InStock

£357.89 GBP

£357.89 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

4K Multi-PC Control Hub

In stock, 1 unit

EAN: 4719264649424

SKU: CS1824

Vendor: ATEN

Order within xx hours for delivery on

Product Specification

Control four HDMI computers from a single console
Supports 4K UHD and 4K DCI video resolution at 60Hz
Built-in 2-port USB 3.0 hub with up to 5Gbps transfer speed
Audio Mixer Mode combines audio from two computers
Video DynaSync™ technology optimizes display resolution
Independent switching of KVM, USB peripherals, and audio
Multiple switching methods: hotkeys, mouse, push button, RS-232
HDMI 2.0 and HDCP 2.2 compliant
Auto Scan mode for monitoring connected computers
Firmware upgrade support

Box Content

1 × ATEN CS1824 4-Port USB 3.0 4K HDMI KVMP Switch
4 × HDMI 2.0 Cables
4 × USB 3.0 Cables
4 × Audio Cables
1 × Power Adapter

Documents

Datasheet

Technical Features

Brand: ATEN
Model: CS1824
Product Type: 4-Port USB 3.0 HDMI KVMP Switch
Computer Connections: 4
Console Ports: 2 × USB Type-A, 1 × HDMI, 2 × 3.5mm Audio
KVM Ports: 4 × HDMI, 4 × USB 3.1 Gen1 Type-B, 4 × 3.5mm Audio
USB Hub: 2 × USB 3.1 Gen1 Type-A (5Gbps)
Video Resolution: Up to 4096 × 2160 @ 60Hz
HDMI Standard: HDMI 2.0
HDCP Support: HDCP 2.2
Port Selection: Push Button, Hotkey, Mouse, RS-232
Scan Interval: 1–99 seconds
Power Input: DC Adapter
Operating Temperature: 0°C – 40°C
Storage Temperature: −20°C – 60°C
Humidity: 0–80% RH (Non-condensing)
Housing: Metal / Plastic
Dimensions: 27.0 × 8.8 × 5.55 cm
Weight: Approx. 0.94 kg

ATEN 4 PORT HDMI 4K60 KVMP

£357.89 GBP

£357.89 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Overview

The ATEN CS1824 4-Port USB 3.0 4K HDMI KVMP™ Switch with Audio Mixer Mode is a professional KVM solution designed for environments requiring control of multiple systems from a single workstation. It allows one keyboard, mouse, and HDMI display to manage up to four computers while sharing USB peripherals such as printers or external drives. The switch supports 4K UHD (3840×2160 @ 60Hz) and 4K DCI (4096×2160 @ 60Hz) for high-quality visuals. Its built-in USB 3.1 Gen 1 hub provides data transfer speeds up to 5Gbps, making it ideal for multimedia tasks. The unique Audio Mixer Mode enables audio signals from two connected computers to be mixed and output simultaneously, ensuring important alerts are never missed. With Video DynaSync™, EDID management, hotkey switching, and RS-232 control, the CS1824 offers reliable and flexible multi-computer control for professional workspaces.
