ATEN 4 PORT DUAL-LINK DVI KVMP

Name: ATEN 4 PORT DUAL-LINK DVI KVMP
Brand: ATEN
SKU: CS1784A
Price: 312.96 GBP
Availability: InStock

£312.96 GBP

£312.96 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

Dual Link Multi-PC Control

In stock, 1 unit

EAN: 4710423777095

SKU: CS1784A

Vendor: ATEN

Order within xx hours for delivery on

Product Specification

Control up to four computers from a single USB console
Supports DVI Dual Link resolution up to 2560 × 1600
Integrated 2-port USB 2.0 hub for peripheral sharing
2.1 channel surround sound audio support
Video DynaSync™ technology optimizes display resolution
Multiple switching methods including push buttons, hotkeys, and mouse
Independent switching of KVM, USB hub, and audio
Compatible with Windows, Linux, Mac, and Sun systems
Supports widescreen resolutions and HDCP compatibility
Auto Scan mode for monitoring multiple computers

Box Content

1 × ATEN CS1784A 4-Port USB DVI Dual Link/Audio KVMP™ Switch
4 × Custom DVI-D USB KVM Cable Sets
1 × Power Adapter
1 × User Instructions

Documents

Datasheet

Technical Features

Brand: ATEN
Model: CS1784A
Product Type: 4-Port USB DVI Dual Link/Audio KVMP™ Switch
Computer Connections: 4
Console Ports: 1 × DVI-I Female, 2 × USB Type-A, 2 × 3.5mm Audio (Mic/Speaker)
KVM Ports: 4 × DVI-I Female, 4 × USB Type-B, 4 × 3.5mm Audio (Mic/Speaker)
USB Hub: 2 × USB 2.0 Type-A
Video Resolution: 2560 × 1600 @ 60Hz (Dual Link), 1920 × 1200 @ 60Hz (Single Link)
Audio Support: 2.1 Channel Surround Sound
Switching Methods: Push Button, Hotkeys, Mouse
Scan Interval: 1–99 Seconds
Power Consumption: DC 5.3V, approx. 5.9W
Operating Temperature: 0°C – 50°C
Storage Temperature: −20°C – 60°C
Humidity: 0–80% RH (Non-condensing)
Housing: Metal
Dimensions: 27.0 × 8.8 × 5.55 cm
Weight: Approx. 0.93 kg

ATEN 4 PORT DUAL-LINK DVI KVMP

£312.96 GBP

£312.96 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Overview

The ATEN CS1784A 4-Port USB DVI Dual Link/Audio KVMP™ Switch provides centralized control of multiple computers from one console while enabling USB peripheral and audio sharing. Designed for professional environments, it supports DVI Dual Link video up to 2560 × 1600 resolution, delivering clear and detailed display performance for graphics-intensive applications. The integrated 2-port USB 2.0 hub allows users to share peripherals such as printers, scanners, and external storage devices between connected systems. It also supports 2.1 channel surround sound, ensuring high-quality audio for multimedia use. Users can switch between computers using front-panel buttons, hotkeys, or mouse commands, while ATEN’s Video DynaSync™ technology maintains optimal display resolution during switching. With multi-platform compatibility including Windows, Linux, Mac, and Sun, the CS1784A is ideal for professional workstations and IT environments.
