ATEN 4 Port Dual HDMI 4K60 KVMP

Name: ATEN 4 Port Dual HDMI 4K60 KVMP
Brand: ATEN
SKU: CS1844
Price: 580.97 GBP
Availability: InStock

£580.97 GBP

£580.97 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

Control Four PCs Seamlessly

In stock, 3 units

EAN: 4710469340048

SKU: CS1844

Vendor: ATEN

Order within xx hours for delivery on

Product Specification

Control four HDMI computers from a single console
Supports dual HDMI displays with True 4K resolution
Integrated USB 3.1 Gen 1 hub with 5 Gbps transfer speed
Exclusive ATEN Video DynaSync technology for optimal display switching
Multiple switching methods including hotkeys and remote port selector
Independent switching of KVM, USB peripherals, and audio
HDMI 2.0 and HDCP 2.2 compliant
Auto Scan mode for monitoring connected computers
Hot-pluggable design with firmware upgrade support
Ideal for graphic design, CAD, CGI, and multimedia workstations

Box Content

1 x ATEN CS1844 4-Port USB 3.0 4K HDMI Dual Display KVMP Switch
8 x HDMI 2.0 Cables
4 x USB 3.0 Cables
4 x Speaker Cables
4 x Microphone Cables
1 x Power Adapter
1 x Remote Port Selector
1 x User Instructions

Documents

Datasheet

Technical Features

Brand: ATEN
Model: CS1844
Product Type: 4-Port USB 3.0 HDMI Dual Display KVMP Switch
Computer Connections: 4
Console Ports: 2 x HDMI, 2 x USB Type-A (Keyboard/Mouse)
KVM Ports: 8 x HDMI, 4 x USB 3.1 Gen 1 Type-B
USB Hub: 2 x USB 3.1 Gen 1 Type-A
Video Resolution: Up to 4096 x 2160 @ 60Hz
HDMI Compliance: HDMI 2.0
HDCP Support: HDCP 2.2
Audio Ports: 3.5 mm microphone and speaker jacks
Data Transfer Rate: Up to 5 Gbps
Port Selection: Pushbutton, Hotkey, Mouse, RS-232, Remote Port Selector
Power Consumption: DC 12V
Housing: Metal
Dimensions: 33.5 x 16.05 x 4.4 cm
Weight: Approx. 1.57 kg

ATEN 4 Port Dual HDMI 4K60 KVMP

£580.97 GBP

£580.97 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Overview

The ATEN CS1844 4-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch is designed for professional workstations that require seamless control of multiple computers using a single console. It enables users to manage up to four HDMI-enabled systems from one USB keyboard, mouse, and two HDMI monitors, improving efficiency in multi-system environments such as graphic design, CGI production, CAD engineering, and video editing.

The switch supports HDMI 2.0 with True 4K resolution (4096 × 2160 @ 60Hz), ensuring crystal-clear visuals for high-resolution workflows. It also features ATEN’s Video DynaSync™ technology, which optimizes display resolution and speeds up switching between computers while maintaining consistent monitor configurations.

A built-in USB 3.1 Gen 1 hub with 5 Gbps transfer speeds allows connected computers to share USB devices such as printers, external drives, or webcams. Multiple switching methods including pushbuttons, hotkeys, mouse switching, RS-232 commands, and a remote port selector provide flexible control options.
