ATEN 2 PORT DP 4K60 MST KVMP

Name: ATEN 2 PORT DP 4K60 MST KVMP
Brand: ATEN
SKU: CS1922M
Price: 488.35 GBP
Availability: InStock

£488.35 GBP

£488.35 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

Dual PC 4K Control

In stock, 1 unit

EAN: 4719264645822

SKU: CS1922M

Vendor: ATEN

Order within xx hours for delivery on

Product Specification

Control two computers from a single console
Supports 4K UHD and 4K DCI resolution at 60Hz
Built-in MST hub enables dual-display configuration
Integrated USB 3.0 hub for high-speed peripheral sharing
DisplayPort Dual-Mode (DP++) supports HDMI/DVI adapters
Independent switching for KVM, USB hub, and audio
Multiple switching methods including hotkeys and push buttons
Hot-plug support for connecting devices without shutdown
Auto Scan mode for monitoring connected systems
Compatible with Windows, Linux, and macOS

Box Content

1 × ATEN CS1922M 2-Port USB 3.0 4K DisplayPort MST KVMP Switch
2 × DisplayPort Cables
2 × USB 3.0 Cables
4 × 3.5mm Audio Cables
1 × Power Adapter

Documents

Datasheet

Technical Features

Brand: ATEN
Model: CS1922M
Product Type: 2-Port USB 3.0 4K DisplayPort MST KVMP Switch
Computer Connections: 2
Console Ports: 2 × USB Type-A, 1 × DisplayPort, 1 × HDMI, 2 × 3.5mm Audio (Mic/Speaker)
KVM Ports: 2 × DisplayPort 1.2, 2 × USB 3.1 Gen1 Type-B, 2 × 3.5mm Audio (Mic/Speaker)
USB Hub: 2 × USB 3.1 Gen1 Type-A (SuperSpeed up to 5Gbps)
Maximum Resolution: 4096 × 2160 @ 60Hz
Video Standard: DisplayPort 1.2
Port Selection: Push Button, Hotkey, Mouse, RS-232
Scan Interval: 1–99 seconds
Power Consumption: DC 5V, approx. 3.44W
Operating Temperature: 0°C – 50°C
Storage Temperature: −20°C – 60°C
Humidity: 0–80% RH (Non-condensing)
Housing: Metal / Plastic
Dimensions: 21.0 × 8.8 × 5.55 cm
Weight: Approx. 0.73 kg

ATEN 2 PORT DP 4K60 MST KVMP

£488.35 GBP

£488.35 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Overview

The ATEN CS1922M 2-Port USB 3.0 4K DisplayPort MST KVMP™ Switch is designed for high-performance workstations requiring centralized control of multiple computers. It supports DisplayPort 1.2 and 4K video resolution up to 4096 × 2160 at 60Hz, delivering crisp and detailed visuals for professional environments. The built-in MST hub enables dual-monitor output from a single DisplayPort source, improving productivity in multi-display workflows. A USB 3.1 Gen1 hub with up to 5Gbps transfer speeds allows users to share high-speed peripherals such as external drives, printers, and webcams. The switch supports multiple switching methods including front-panel buttons, hotkeys, mouse switching, and RS-232 commands. With independent switching of KVM, USB hub, and audio, plus hot-plug support, the CS1922M is ideal for design studios, financial trading desks, and control rooms.
