Logitech Rally Bar Mini + Tap Cat5 video conferencing system Ethernet LAN

Logitech Rally Bar Mini + Tap Cat5 video conferencing system Ethernet LAN

£3,521.44 GBP
Sale price: £3,521.44 GBP Regular price: £0.00 GBP
(VAT Incl.)
Shipping calculated at checkout.
  • Echo cancellation
  • RMS rated power: 8 W
  • Built-in speaker
Out of stock
EAN: 715663106487
SKU: TAPRMGUNIAPP
Vendor: Logitech
Order within xx hours for delivery on
Quantity
  • Type: Video Conferencing Systems
  • Cable lock slot type: Kensington
  • Cable lock slot: Yes
  • Motion sensor: Yes
  • Telepresence: No
  • Number of microphones: 6
  • Sound pressure level (max): 90 dB
  • Microphone direction type: Omnidirectional
  • Microphone frequency: 90 - 16000 Hz
  • Microphone sensitivity: -36 dB

Camera included
Quick start guide
Remote control included
Mounting kit
AC adapter included
HDMI cable length: 2 m
Power cable length: 1.5 m
Cables included: AC, DC, HDMI, USB Type-A to USB Type-C

Datasheet

Overview

Logitech Rally Bar Mini raises the bar for video meetings in small and medium rooms. Rally Bar Mini is remarkably simple to deploy, use, and manage remotely. Plug and play Rally Bar Mini with any PC or laptop, or leverage its built-in compute and use it in appliance mode. Rally Bar Mini works with most platforms you use to connect hybrid teams, ensuring an effortless experience from the home to the office, and everywhere in between.

Technical Features
  • Audio
    • Driver diameter: 7 cm
    • Echo cancellation: Yes
    • Microphone pick-up range: 4.5 m
    • Noise reduction: Yes
    • RMS rated power: 8 W
    • Sample rates: 0 - 48 kHz
    • Audio beamforming: Yes
    • Output voltage Total Harmonic Distortion (THD): 2%
    • Line-out impedance: 4 Ω
    • Output level: 92/99 dB
    • Built-in speaker(s): Yes
  • Camera
    • Remote control interface: Bluetooth
    • Diagonal field of view: 120°
    • Vertical field of view: 80.7°
    • Horizontal field of view: 113°
    • Digital zoom: 4x
    • Zoom capability: Yes
  • Computer system
    • Mac operating systems supported: Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
    • Windows operating systems supported: Windows 10, Windows 11
  • Display
    • Oleophobic coating: Yes
    • Display brightness: 400 cd/m²
    • Viewing angle, horizontal: 85°
    • Viewing angle, vertical: 85°
    • Touchscreen type: Capacitive
    • Touchscreen: Yes
    • Contrast ratio (typical): 1000:1
    • Display resolution: 1280 x 800 pixels
    • Display diagonal: 25.6 cm (10.1")
    • Display: IPS
  • Network
    • Security algorithms: 128-bit AES
    • Supported network protocols: IPv4, IPv6
    • Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
    • Wi-Fi: Yes
    • Ethernet LAN data rates: 10, 100, 1000 Mbit/s
    • Ethernet LAN: Yes
  • Operational conditions
    • Operating relative humidity (H-H): 10 - 95%
    • Operating temperature (T-T): 0 - 40 °C
    • Storage temperature (T-T): -40 - 70 °C
  • Performance
    • PTZ control: Yes
    • Tilt angle range: -15 - 15°
    • Pan range: -25 - 25°
    • Product colour: Graphite
  • Ports & interfaces
    • Microphone in: Yes
    • DC-in jack: Yes
    • USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
    • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
    • USB connector type: USB Type-A, USB Type-C
    • HDMI input ports quantity: 1
    • HDMI output ports quantity: 2
    • HDMI ports quantity: 3
  • Power
    • DC input voltage: 19 V
    • Current: 4.74 A
    • AC input voltage: 100 - 240 V
    • Power source type: AC
  • Video
    • Maximum frame rate: 30 fps
    • Supported video modes: 576p, 720p, 900p, 1440p, 2160p
    • Maximum video resolution: 3840 x 2160 pixels
    • HD type: 4K Ultra HD
  • Weight & dimensions
    • Weight: 4.03 kg
    • Height: 91.4 mm
    • Depth: 101 mm
    • Width: 719 mm
    • Interface module weight: 1.25 kg
    • Interface module dimensions (W x D x H): 244 x 179 x 58 mm
