Logitech MeetUp

Camera:

• Custom Logitech lens with 5x HD zoom and motorized pan (+/- 25°) and tilt (+/- 15°)
• Field of view: Diagonal: 120°, Horizontal: 113°, Vertical: 80.7°
• Total Room Coverage (field of view + pan and tilt): 163° wide x 110° tall
• 3 camera position presets
• RightSight auto-framing (requires Windows 10 64-bit; macOS coming soon)
• Video performance:
• 4K Ultra HD video calling (up to 3840 x 2160 pixels @ 30 fps with customer-supplied USB 3.0 cable)
• 1080p Full HD video calling (up to 1920 x 1080 pixels @ 30 fps)
• 720p HD video calling (up to 1280 x 720 pixels @ 30 fps)

Microphone:

• Pickup Range - MeetUp: 4 meters (13.1 feet)
• With optional Expansion: 5 meters (16.4 feet)
• Sensitivity: -27dB
• Microphone frequency response: 90Hz – 16kHz for full voice reproduction and high intelligibility without noise
• Beamforming performance: Factory-paired, very low distortion broadside beamforming algorithm steers the pickup range directly at the speaker for the best voice pickup and noise reduction
• AEC (Acoustic echo cancellation)
• VAD (Voice activity detector)
• Background noise suppression
• 32 kHz sampling rate
• Recommended # of participants: 6
• Recommended # of participants with expansion mic: 8

Speaker:

• Volume adjustable to 95 dB SPL at 1/2-meter peak
• Speaker sensitivity 86.5+/-3dB SPL at 1/2 meter
• Distortion: 200 Hz – 300Hz < 3%, 3000 Hz -10KHz < 1%
• Patent-pending anti-vibration enclosure improves voice clarity while limiting sound transmission to adjacent spaces
