DrayTek Vigor 166 VDSL/G.Fast Modem

Name: DrayTek Vigor 166 VDSL/G.Fast Modem
Brand: DrayTek
SKU: 253362
Price: 143.81 GBP
Availability: InStock

£143.81 GBP

£143.81 GBP ~~Regular price: £0.00 GBP~~

(VAT Incl.)

Shipping calculated at checkout.

Support up to 330Mbps download
IPv6 and IPv4 Compatible

In stock, 199 units

EAN: 4712909128230

SKU: 253362

Vendor: DrayTek

Order within xx hours for delivery on

Product Specification

Wall Mountable: Yes
Operating Temperature: 0 °C ~ 45 °C
Storage Temperature: -25 °C ~ 70 °C
Humidity: 10% ~ 90% (non-condensing)
Power Consumption: 6.6 Watt Max.
Length: 181mm
Width: 125mm
Height: 40mm
Weight: 280g
Operating Power: DC 12V 1A (via external PSU, supplied)
Power Requirements: 220-240VAC

Box Content

• Vigor 166 Modem
• Quick Start Guide
• RJ-11 DSL Cable
• Cat-5e RJ-45 Cable
• Screws & wall plugs for wall mounting
• DC 12V PSU

Documents

Datasheet

Technical Features

G.fast & VDSL2 35b Capable: Up to 330Mbps download and 50Mbps upload with G.fast technology. Compatible with all the latest DSL standards, including Vectoring and 35b SuperVectoring.
Two Gigabit LAN Ports: Connect two devices to the Vigor 166 with 2 Gigabit (10/100/1000Mbps) LAN ports. No need to disconnect Ethernet WAN to check connectivity.
No Setup Needed: Works as a modem with most ISPs, straight out of the box. Pre-configured to work with most UK ISPs—just set the username and password on your router.
Full-Bridge Modem and More: Two operation modes allow the Vigor 166 to operate as a fully bridged DSL to Ethernet modem or as a mini router with NAT DMZ host.
Add DSL Connectivity to Any Router: Ideal partner device for DrayTek dual-WAN products or any other vendor's Ethernet WAN firewall. Reports DSL line status on DrayTek Vigor routers.
Wall or Shelf Mountable: Can be securely installed on a wall or shelf with screw fixings to hold it in place. Mounting kit included.
