ATEN SN3401P

ATEN SN3401P

£196.78 GBP
Sale price: £196.78 GBP Regular price: £0.00 GBP
(VAT Incl.)
Shipping calculated at checkout.
  • Secure Serial Networking Made Simple
In stock, 1 unit
EAN: 4710469341540
SKU: SN3401P
Vendor: ATEN
Order within xx hours for delivery on
Quantity
  • Provides secure serial-to-Ethernet connectivity for remote device management
  • Supports RS-232, RS-422, and RS-485 communication standards
  • IEEE 802.3af PoE support for simplified installation
  • Multiple operation modes including Secure Real COM and TCP Server/Client
  • Supports serial tunneling and console management via SSH or Telnet
  • Integrated Modbus gateway supporting Modbus TCP and Modbus RTU/ASCII
  • Advanced security with TLS encryption and user authentication
  • Built-in surge protection and electrical isolation
  • Web-based GUI for easy configuration and management
  • Flexible mounting options: desktop, wall, DIN rail, or rack
  • 1 × ATEN SN3401P Secure Serial Device Server
  • 1 × Power Adapter
  • 1 × Terminal Block Connector
  • 1 × DIN Rail Mount Kit
  • 4 × Foot Pads
  • 1 × Quick Installation Guide / User Instructions

Datasheet

Overview

The ATEN SN3401P Secure Serial Device Server allows organizations to integrate legacy serial devices into modern IP networks for remote monitoring and control. Supporting RS-232, RS-422, and RS-485 interfaces, it provides reliable serial-to-Ethernet connectivity for industrial equipment, POS systems, access control devices, and SCADA environments. The device supports multiple operating modes including Secure Real COM, TCP server/client, serial tunneling, and console management via SSH or Telnet. With IEEE 802.3af PoE support, the SN3401P can be powered directly through the network cable, reducing wiring complexity. Built-in surge protection, isolation, and advanced authentication features ensure secure and stable communication. Its compact metal housing and flexible mounting options make it suitable for industrial and enterprise deployments.

Technical Features
  • Model: SN3401P
  • Device Type: Secure Serial Device Server
  • Serial Ports: 1
  • Serial Interface: RS-232 / RS-422 / RS-485
  • Ethernet Ports: 1 × RJ-45 (10/100 Mbps)
  • Network Standard: IEEE 802.3af PoE
  • Maximum Baud Rate: Up to 921.6 Kbps
  • Isolation Protection: 1.5 kV
  • ESD Protection: 8 kV
  • Surge Protection: 2 kV
  • Power Input: DC or PoE
  • Power Consumption: Max 1.3 W
  • Operating Temperature: 0°C to 60°C
  • Dimensions: 117 × 98 × 26 mm
  • Weight: Approx. 0.21 kg
  • Housing: Metal
