TP-Link TL-SL1218MP 16P Unman POE Sw

TP-Link TL-SL1218MP 16P Unman POE Sw

£150.95 GBP
Sale price: £150.95 GBP Regular price: £0.00 GBP
(VAT Incl.)
In stock, 23 units
EAN: 6935364099824
SKU: TL-SL1218MP
Vendor: TP-Link
Order within xx hours for delivery on
Quantity
  • Interface: 16 PoE+ 10/100 Mbps RJ45 Ports, 2× 10/100/1000 Mbps RJ45 Ports, 2× Combo Gigabit SFP Slots
  • Network Media: 10BASE-T: UTP category 3, 4, 5 cable (max 100m), EIA/TIA-568 100Ω STP (max 100m); 100BASE-TX: UTP category 5, 5e cable (max 100m), EIA/TIA-568 100Ω STP (max 100m); 1000BASE-T: UTP category 5, 5e, 6 or above cable (max 100m), EIA/TIA-568 100Ω STP (max 100m); 1000BASE-X MMF, SMF
  • Fan Quantity: 2 Fans
  • Physical Security Lock: Yes
  • Power Supply: 100–240V AC, 50/60 Hz
  • PoE Ports (RJ45): Standard: 802.3at/802.3af compliant, PoE Ports: Ports 1–16, PoE Power Budget: 250 W
  • Dimensions (W x D x H): 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
  • Max. Power Consumption: 14.97 W (220/50Hz, no PD connected), 285.8 W (220/50Hz, with 250 W PD connected)
  • Max. Heat Dissipation: 51.05 BTU/h (no PD connected), 974.58 BTU/h (with 250 W PD connected)
  • Switching Capacity: 7.2 Gbps
  • Packet Forwarding Rate: 5.36 Mpps
  • MAC Address Table: 8K
  • Jumbo Frame: 10 KB

TP-Link TL-SL1218MP 16P Unman POE

Quick Installation Guide

Datasheet

Overview

TP-Link's new TL-SL1218MP PoE switch with all 16 ports supporting the PoE+ standard provides a simple way to expand the wired network while transferring power over the same Ethernet cable at the same time. With a total power budget of 192W, up to 30W per port, TL-SL1218MP can power more high-powered devices such as Access Points, IP Cameras, IP Phones and so on. Moreover, with innovative Extend Mode, devices can get PoE power supply and data transmission from 250m's distance. Priority mode ensures high priority for Port 1-8, which guarantees the quality of sensitive applications.16 PoE+ 10/100Mbps RJ45 ports, 2 Gigabit RJ45 ports and 2 combo Gigabit SFP slotsUp to 250m data and power transmission under extend mode specially designed for surveillance systemPriority mode for port1-8 to guarantees the quality of sensitive applications like video monitorHigh PoE power budget with up to 30W for each PoE port and 192W for all PoE portsEasy to use, with no configuration and installation needed

Technical Features
  • 6× PoE+ 10/100 Mbps RJ45 ports, 2× Gigabit RJ45 ports, and 2× combo Gigabit SFP slots.
  • High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports.*
  • Up to 250 m data and power transmission under extend mode specially designed for surveillance system.**
  • Priority mode for ports 1–8 to guarantees the quality of sensitive applications like video monitor.
  • Isolation Mode allows one-click client traffic separation for higher security and performance.
  • Easy to use, with no configuration and installation needed.
