Overview
The TL-LS105GP is a compact unmanaged network switch with advanced functions to ensure effective performance. The switch supports PoE+ on four ports with PoE Auto Recovery to reboot unresponsive PoE devices. The switch also features Extend Mode for long range power & data transmission, which is ideal for surveillance applications
Technical Features
- 10Gb/s Switching capacity with 2K MAC address table
- Four port PoE+ (IEEE 802.3af/at) supporting up to 30W per port
- 65W Total PoE power budget for connected devices
- PoE Auto Recovery function automatically reboots non-responsive PoE-powered devices (Ports 1-4)
- Long range PoE transmission distance up to 250m with Extend Mode, ideal for surveillance cameras (Ports 1-2)
- Auto MDI/MDI-X & auto negotiation
- Plug & play setup and installation, no configuration required
- Compact fanless housing for silent operation
- Dimensions (HxWxD): 25x100x98mm
- UK mains plug (type G), as used in the UK, IRL, Cyprus, Saudi Arabia, Malta and many others.
