LG 55VM5J-H Digital signage display

LG 55VM5J-H Digital signage display

£1,379.87 GBP
Sale price: £1,379.87 GBP Regular price: £0.00 GBP
(VAT Incl.)
Shipping calculated at checkout.
  • Interface: HDMI/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR
  • Digital signage flat panel
In stock, 24 units
EAN: 8806091407702
SKU: 10372178
Vendor: LG
Order within xx hours for delivery on
Quantity
  • Brightness (Typ.): 500 nit
  • Bezel: 1.74mm (Panel Bezel to Panel Bezel), 1.3mm (T/L), 0.44mm (B/R)
  • Depth: 86.9 mm
  • Interface: HDMI/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR
  • USB ports quantity: 1
  • USB version: 2.0
  • Audio (L/R) out: 1
  • Ethernet LAN: Yes
  • DisplayPorts quantity: 1
  • RS-232C: Yes
  • DVI-D ports quantity: 1
  • HDMI ports quantity: 3
  • Audio (L/R) in: 1
  • HDMI input ports quantity: 2
  • Remote (IR) input: 1
  • HDMI output ports quantity: 1
  • Ethernet LAN (RJ-45) ports: 2
  • HDMI version: 2.2
  • DVI port: Yes
  • USB port: Yes
  • VESA mounting: Yes
  • Bezel width (side): 1.75 mm
  • Bezel width (top): 2.49 mm
  • Placement supported: Indoor
  • Bezel width (bottom): 0.74 mm
  • Product colour: Black
  • Panel mounting interface: 600 x 400 mm
  • Product design: Digital signage flat panel
  • Orientation: Horizontal/Vertical

LG 55VM5J-H Digital signage display

Datasheet

Overview

The ultra slim bezel, with its 1.74mm BtoB (Panel Bezel to Panel Bezel), drastically reduces bezel interference and delivers immersive and seamless content on assembled video wall screens. The VM5J-H includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience. Large screens are usually positioned higher than human-eye level. Wide half luminance angle (40) enables effective picture quality for video walls. The viewing angle of the VM5J-H is high enough to display vivid colors throughout the screen without any color distortion. LG IPS panel technology enables stable and smooth control of liquid crystals, and allows the screen to be viewed from virtually any angle. Therefore, the VM5J-H captivates the attention of more viewers with lifelike colors, regardless of their viewing position.

Technical Features
  • Performance
    • International Protection (IP) code: IP5X
    • Open Pluggable Specification (OPS): Yes
    • HDCP: Yes
    • Purpose: Universal
    • Operating hours (hours/days): 24/7
    • HDCP version: 1.4/2.2
  • Power
    • AC input voltage: 100 - 240 V
    • Power consumption (off): 0.5 W
    • Heat dissipation: 648 BTU/h
    • AC input frequency: 50 - 60 Hz
    • Power consumption (typical): 160 W
    • Power consumption (standby): 105 W
    • Energy efficiency class (SDR): G
    • Energy efficiency scale: A to G
    • Energy consumption (SDR) per 1000 hours: 112 kWh
  • Display
    • Touchscreen: No
    • Panel life: 60000 h
    • Haze rate: 28
    • Native aspect ratio: 16:9
    • Contrast ratio (dynamic): 500000:1
    • Native refresh rate: 60 Hz
    • Panel type: IPS
    • Display diagonal: 139.7 cm (55")
    • Display number of colours: 1.07 billion colours
    • Contrast ratio (typical): 1000:1
    • Response time: 8 ms
    • Display resolution: 1920 x 1080 pixels
    • HD type: Full HD
    • RGB colour space: NTSC
    • Viewing angle, vertical: 178
    • Display brightness: 500 cd/m²
    • Viewing angle, horizontal: 178
  • Weight & Dimensions
    • Display depth: 86.9 mm
    • Display weight: 18.8 kg
    • Height: 683 mm
    • Display width: 1212.2 mm
    • Width: 1212.2 mm
    • Depth: 86.9 mm
    • Weight: 18.8 kg
    • Display height: 683 mm
